YCT-16 Semi Automatic High Precision Plane Labeling Machine

Short Description:

This labeling machine is good for all kinds of specifications square,flat,tiny curved and irregular products labeling, such as electronic chip, plastic cover, cosmetic flat bottler, toy cover.


Product Detail

Full auomtaic packing machine solutions

Product Tags

Product Application:

1
66
44

Machine description:

①This labeling machine is good for all kinds of specifications square,flat,tiny curved and irregular products labeling, such as electronic chip, plastic cover, cosmetic flat bottler, toy cover.
②It can achieve full coverage labeling,partial accurate labeling,vertical multi-label labeling and horizontal multi-label labeling, widely used in electron, delicate goods, packaging, cosmetics and packaging materials industries.
③Optional functions: an optional color-matching tape coding machine can be added to the label head, and the production batch, production date and expiration date can be printed at the same time. Reduce packaging process, greatly improve production efficiency, special label sensor.
④The adjustment method is simple: adjustment the high of suction board, adjustment the position of label sensor until one label is all pulled out and install the mould that place the products under the suction board. The adjustment of the process is less than 10 minutes.
⑤Machine floor space about 0.24 stere.
⑥Machine Support Customization.
The labeling machine has high labeling accuracy up to ±0.2mm and good quality, and it is difficult to see the error with the naked eye.

Working principle:

1.After the product is placed in the mold, press the switch, and the machine will pull-out the label out.
2.When one label is all pulled out, the label suction board will adsorb the label, and then the label suction board will move down until the label is glued to the product.
3.Label suction board will return to the original, and the machine will restore, a labeling process is completed.

Label specification:

①Applicable labels: sticker label, film, electronic supervision code, bar code.
②Applicable products: Products that are required to be labeled on flat, arc-shaped,round, concave, convex or other surfaces.
③Application industry: Widely used in cosmetics, food, toys, chemical, electronics, medicine and other industries.
④Application examples: shampoo flat bottle labeling, packaging box labeling, bottle cap, plastic shell labeling, etc.

label production requirements:

1. The gap between the label and the label is 2-3mm;
2. The distance between the label and the edge of the bottom paper is 2mm;
3. The bottom paper of the label is made of glassine, which has good toughness and prevents it from breaking (to avoid cutting the bottom paper);
4. The inner diameter of the core is 76mm, and the outer diameter is less than 280mm, arranged in a single row.
The above label production needs to be combined with your product. For specific requirements, please refer to the results of communication with our engineers!

pro

Main Structure:

No. Structure Function
1 Label Tray Place the label roll
2 Rollers Wind the label roll
3 Label Sensor Detect label
4 Label-sending Cylinder Send label below the labeling head
5 Label-peeling Cylinder Drive the labeling head to get label from the release paper
6 Labeling Cylinder Drive the labeling head to stick label to pointed position
7 Labeling Head Get label from the release paper and stick to product
8 Product Fixture Custom-made,fix product while labeling
9 Traction Device Driven by traction motor to draw the label
10 Release Paper Recycling Recycle the release paper
11 Emergency Stop Stop the machine if it runs wrong
12 Electric Box Place electronic configurations
13 Touch Screen Operation and setting parameters
14 Air Circuit Filter Filter water and impurities

Technical parameters:

Parameter Date
Label Specification Adhesive sticker,transparent or opaque
Labeling Tolerance ±0.2mm
Capacity(pcs/min) 15~30
Suit bottle size(mm) L:20~200 W:20~180 H:0.2~85;Can be customized
Suit label size(mm) L:10-70;W(H):5-70
Machine Size(L*W*H) 600*500*800(mm)
Pack Size(L*W*H) 650*550*850(mm)
Voltage 220V/50(60)HZ;Can be customized
Power 330W
N.W(KG) 45.0kg
G.W(KG) 67.5kg
Label Roll ID:Ø76mm; OD:≤240mm
Air Supply 0.4~0.6Mpa

Features:

1 ) Control System: Japan Panasonic control system , with high stability and extremely low failure rate.
2 ) Operation System: Touch screen , directly visual interface easy operation. Chinese and English are available . Easily to adjust all electrical parameters and have counting function , which is helpful for production management.
3) Detection System: German LEUZE/Italian Datalogic label sensor and Japan Panasonic product sensor , which are sensitive to label and product , thus ensure high accuracy and stable labeling performance . Greatly saves labor .
4) Alarm Function : The machine will give an alarm when problem occur , such as label spill , label broken , or other malfunctions .
5) Machine Material : The machine and spare parts all use material stainless steel and anodized senior aluminum alloy , with high corrosion resistance and never rust .
6) Equip with a voltage transformerto adapt to local voltage.
